- Processor Main Frequency: Depends on CPU
- Use: Commercial
- Memory Capacity: ≥ 4GB
- Hard Drive Capacity: 512GB
- Model Number: ITPC1
- Processor Brand: Intel
- Processor Model: Intel Core
- Type: Mini Desktop
- Graphics Card Type: Integrated Card
- Brand Name: Topton
- Origin: Mainland China
- Certification: CE
- Type: MINI PC
- System: Windows 7/8/10, Linux, Ubuntu etc
- Size: 376.1×285.3×58.7 mm
- Touch Screen Type: Capacitive(Resistive optional)
- Memory type: Onboard 4GB/8GB
- Storage Type: 1*mSATA SSD+1*2.5''SATA SSD/HDD
- Display: LCD+HD dual display
- Network port: 2*GbE RJ45 Intel i211-AT
- GPIO port: 1*14bit GPIO
- COM port: 2*DB9 RS232/422/485
- Installation method: VESA 75/panel mounting
Processor parameter for referance:
1. Intel Celeron J1900, 2M Cache, 4 cores 4 threads, 2.00 GHz up to 2.42GHz;
2. Intel Core i5-4200U, 3M Cache, 2 cores 4 threads, 1.60 GHz up to 2.60GHz;
3. Intel Core i7-4500U, 4M Cache, 2 cores 4 threads, 1.80 GHz up to 3.00GHz;
4. Intel Core i5-6200U, 3M Cache, 2 cores 4 threads, 2.30 GHz up to 2.80GHz;
5. Intel Core i7-6500U, 4M Cache, 2 cores 4 threads, 2.50 GHz up to 3.10GHz;
6. Intel Core i5-7267U, 4M Cache, 2 cores 4 threads, 3.10 GHz up to 3.50GHz;
7. Intel Core i5-8250U, 6M Cache, 4 cores 8 threads, 1.60 GHz up to 3.40GHz;
8. Intel Core i7-8550U, 8M Cache, 4 cores 8 threads, 1.80 GHz up to 4.00GHz.
Touch Screen
Type: Capacitive, support ten-point touch(Resistive optional)
Waterproof&Dustproof Level: IP65
LCD Size: 15" TFT LCD
Aspect Ratio: 4:3
Resolution: 1024 x 768
Luminance: 350cd/m2
Max Color: 16.7M
Viewing angle (CR>=10): -85~85° (H), -85~85° (V)
Backlit: LED
Highlight
– Industrial-grade anless system without cooling fan, no any noise, thicker and longer heat-sink fins for working as long as 7×24 hours durably;
– Capacitive Touch Screen IP65 level waterproof and dustproof, support Ten-point sensitive touch;
– LCD+HD dual display synchronously and asynchronously;
– 1xmSATA SSD+1×2.5''SATA SSD/HDD installation supported;
– 2xGigabit Ethernet RJ45 Intel i211-AT;
– 2xDB-9 COM1&COM2, support RS-232/422/485;
– 1x14bit GPIO, 7 ways input, 7 ways output;
– One embedded SIM card slot onboard, 3G/4G/WiFi optional;
– 9-36V Wide voltage input;
– Support Watchdog, Auto Power On, RTC, Wake On Lan, PXE, Reset etc functions.
Package List
1xIndustrial tablet pc,
1xPower Adapter,
1xPower Cord,(we ship correct power plug base on buyer's address)
1xScrews Bag
All bundles on sale DO NOT include WiFi/3G/4G module, WiFi module cost US $10, 3G module cost US $50, 4G module cost US $70. 500GB 2.5'' HDD add extra 50$, 1TB 2.5'' HDD add extra 65$, 2TB 2.5'' HDD add extra 100$.If you need, pay at this link.
|
Basic Information: |
|
|
CPU |
Intel Celeron J1900/ Intel 4th/6th/7th/8th Gen Core i5/i7 |
|
TDP |
15W |
|
Chipset |
Refer to CPU |
|
Memory |
Onboard 4GB/8GB RAM |
|
OS |
Windows 7/Windows 8/Windows 10/Linux/ WES7 |
|
Watchdogtimer |
1 ~ 255 seconds programmable |
|
Videocard |
Refer to CPU |
|
Input/output port |
|
|
Switch |
1 x Power On/Off Switch |
|
Power |
1 x DC 9 ~ 36V 3-pin Phoenix Terminal |
|
Amplifier |
2 x 8Ω 1W Amplifier output (Optional) |
|
USB |
4x USB3.0(3xUSB2.0, 1xUSB3.0 for J1900), Built-in 1xUSB2.0 Dongles Port |
|
Display |
1 x HD |
|
LAN |
2x Gigabit Ethernet RJ45 Intel i211-AT |
|
Audio |
1 x Audio Line-out |
|
COM |
2 x DB-9 COM1&COM2,RS-232/422/485 |
|
GPIO |
1 x 14bit GPIO (Optional) |
|
Others |
2 x 3-wire COM3&COM4 RS-232/485 Phoenix Terminal 2 x 3-wire COM5&COM6 RS-232 Phoenix Terminal 1x Phoenix terminal remote switch interface |
|
Storage |
|
|
MSATA |
1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s |
|
SATA |
1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s |
|
Wi-Fi |
|
|
Module |
1x Mini PCIE Half port for WiFi module 1x Mini PCIE Full port for 3G/4G module |
|
Antenna |
2 x inner RF cables without external antennas |
|
Power and Working Environment |
|
|
Input |
DC 9 ~ 36V 3-pin Phoenix Terminal |
|
Operating Temperature |
-20°C ~ 60°C |
|
Storage Temperature |
-30°C ~ 70°C |
|
Storage Humidity |
10~90% @30°C, non-condensing |
|
Display Information |
|
|
LCD Type |
TFT-LCD |
|
Resolution |
Refer to screen size |
|
Max color |
16.2M |
|
Brightness |
350 cd/m² |
|
Perspective (CR>=10) |
-85~85° (H), -85~85° (V) |
|
Backlight |
LED |
|
Backlight life (hour) |
50,000 |
|
Product Dimension & Details |
|
|
Size |
Refer to screen size |
|
Weight |
Refer to screen size |
|
Shell |
Silver color aluminum alloy(any customized color for bulk order) |
|
Installation method |
VESA 75/ Panel mounting |
|
Cooling Mode |
Fanless |
|
Package Content |
|
|
Standard |
1xIndustrial tablet PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag |
|
Touch Screen Information |
|
|
Type |
Capacitive by default(Resistive optional) |
|
Transmitiance |
78% |
|
Lifetime |
250g clicks 10 milliontimes |
